22 TECHNICAL DATA 173

Screw, unlocking of timing chain ten-

sioner

M10x1 10 Nm (7.4 lbf ft) –

Spark plug outside M10x1 11 Nm (8.1 lbf ft) –

Spark plug inside M12x1.25 18 Nm (13.3 lbf ft) –

Coolant temperature sensor on cylinder

head

M12x1.5 12 Nm (8.9 lbf ft) –

Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –

Screw plug, oil channel M14x1.5 15 Nm (11.1 lbf ft) Loctite

243™

Engine case stud M16x1.5 25 Nm (18.4 lbf ft) Loctite

243™

Rotor nut M18x1.5 100 Nm (73.8 lbf ft) –

Nut, engine sprocket M20x1.5 80 Nm (59 lbf ft) Loctite

243™

Nut, inner clutch hub M20x1.5 100 Nm (73.8 lbf ft) Loctite

243™

Nut, primary gear M20LHx1.5 90 Nm (66.4 lbf ft) Loctite

243™

Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –

Plug, timing chain tensioner M20x1.5 25 Nm (18.4 lbf ft) –

Plug, oil thermostat M24x1.5 15 Nm (11.1 lbf ft) –

Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –

22.3 capacities

22.3.1 Engine oil

Engine oil 1.70 l (1.8 qt.) Engine oil (SAE 10W/60) (00062010035) ( p. 183)

Alternative engine oil Engine oil (SAE 10W/50)

( p. 184)

Other manuals for KTM 690 SMC R

Questions and Answers:

Need help?

Do you have a question about the KTM 690 SMC R and is the answer not in the manual?

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
