KTM 690 SMC R User Manual

22 TECHNICAL DATA 176
Fuse 75011088010 10 A
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal RY10W / socket BAU15s 12 V
10 W
Brake/tail light LED
License plate lamp W5W / socket W2.1x9.5d 12 V
5 W
22.6 Tires
Front tires Rear tires
120/70 R 17 M/C 58H TL
Continental Conti Attack SM
160/60 R 17 M/C 69H TL
Continental Conti Attack SM
Additional information is available in the Service section under:
http://www.ktm.com
22.7 Fork
Fork part number 14.18.8N.12
Fork WP Performance Systems 4860 ROTA SPLIT
Compression damping
Comfort 20 clicks
Standard 15 clicks

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
