13 WHEELS, TIRES 103
101999-10
– Take the motorcycle off of the front wheel stand. ( p. 72)
– Operate the front brake and compress the fork a few times firmly.
The fork legs straighten.
–
Tighten screws
.
Guideline
Screw, fork stub M8 15 Nm
(11.1 lbf ft)
Finishing work
– Remove the rear of the motorcycle from the wheel stand. ( p. 71)
13.3 Removing the rear wheel
Preparatory work
– Raise the motorcycle with the rear wheel stand. ( p. 70)
102000-10
Main work
– Press the brake caliper onto the brake disc by hand in order to push back the brake pis-
ton.
–
Remove screw
and pull wheel speed sensor
out of the hole.
–
Remove nut
. Remove chain adjuster
.
