KTM 690 SMC R User Manual

20 TROUBLESHOOTING 160
Faults Possible cause Action
The engine does not turn when the
starter button is pressed
Operating error – Carry out the start procedure. ( p. 47)
The battery is discharged – Recharge the battery. ( p. 117)
– Check the quiescent current.
Fuse 1 or 2 blown – Change the fuses of individual power consumers.
( p. 123)
– Set the clock. ( p. 32)
Main fuse burned out – Change the main fuse. ( p. 120)
No ground connection present – Check the ground connection.
Engine turns only if the clutch lever is
drawn
The vehicle is in gear – Shift gear to neutral.
The vehicle is in gear and the side
stand is folded out
– Shift gear to neutral.
Engine turns but does not start. Operating error – Carry out the start procedure. ( p. 47)
Fuse 3 blown – Change the fuses of individual power consumers.
( p. 123)
The plug-in connection of the fuel hose
connection is not connected
– Connect the plug-in connection of the fuel line.
Defect in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
Engine has too little power. Air filter is very dirty – Remove the air filter. ( p. 76)
– Install the air filter. ( p. 77)
Fuel screen is very dirty – Change fuel screen.
Fuel filter is very dirty – Check the fuel pressure.
Defect in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
