KTM 690 SMC R User Manual

22 TECHNICAL DATA 170
3rd gear 21:28
4th gear 21:23
5th gear 23:22
6th gear 23:20
Mixture preparation Electronic fuel injection
Ignition Contactless controlled fully electronic ignition with digital ignition
adjustment
Alternator 12 V, 224 W
Spark plug
Inside spark plug NGK LKAR8BI-9
Outside spark plug NGK LMAR7A-9
Spark plug electrode gap 0.9 mm (0.035 in)
Cooling Water cooling, permanent circulation of coolant by water pump
Starting aid Electric starter, automatic decompressor
22.2 engine tightening torques
Screw, membrane fixation M3 2 Nm (1.5 lbf ft) Loctite
®
243™
Hose clamp, intake flange M4 2.5 Nm (1.84 lbf ft) –
Oil nozzle for conrod bearing lubrication M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Locking screw for bearing M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Remaining screws, engine M5 6 Nm (4.4 lbf ft) –
Screw, breather cover on valve cover M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, clutch spring M5x25 6 Nm (4.4 lbf ft) –
Screw, cover plate for oil return line M5 6 Nm (4.4 lbf ft) –

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
