KTM 690 SMC R User Manual

22 TECHNICAL DATA 171
Screw, gear position sensor M5x16 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, oil filter cover M5x16 6 Nm (4.4 lbf ft) –
Screw, oil pump cover, top M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Cylinder head screw M6x25 10 Nm (7.4 lbf ft) Loctite
®
243™
Plug, vacuum connection M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Remaining screws, engine M6 10 Nm (7.4 lbf ft) –
Screw, alternator cover M6x25 10 Nm (7.4 lbf ft) –
Screw, alternator cover (chain shaft
through-hole)
M6x25 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, autodecompression M6 3… 4 Nm (2.2… 3 lbf ft) Loctite
®
243™
Screw, axial lock of camshaft M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, clutch slave cylinder M6x35 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, crankshaft position sensor M6x16 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, cylinder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, engine case M6 10 Nm (7.4 lbf ft) –
Screw, ignition coil M6 10 Nm (7.4 lbf ft) –
Screw, locking lever M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil pump cover, bottom M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, rocker arm shaft M6x30 12 Nm (8.9 lbf ft) –
Screw, shift drum locating M6x30 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, starter motor M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, stator M6 10 Nm (7.4 lbf ft) Loctite
®
243™

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
