8 RIDING INSTRUCTIONS 52
– If the engine stalls (e.g. at a crossroads), just pull the clutch lever and press the elec-
tric starter button. You do not have to shift into neutral.
– Switch off the engine if running at idle or standing for a long time.
– Avoid frequent and longer slipping of the clutch. This heats the engine oil, the engine,
and the cooling system.
– Ride with a lower engine speed instead of with a high engine speed and a slipping
clutch.
– Stop immediately if the FI warning lamp (MIL) lights up during a trip. When you shift to
neutral, the FI warning lamp (MIL) starts to flash.
Info
From the flash rhythm you can deduce a two-digit number, the so-called blink
code. The blink code tells you which component is affected by a malfunction.
8.5 Applying the brakes
Warning
Danger of accidents Reduced braking efficiency due to a wet or dirty brake system.
– Clean or dry a dirty or wet brake system by riding and braking gently.
Warning
Danger of accidents Reduced braking efficiency caused by spongy pressure point of front or rear brake.
– Check the brake system and do not continue riding. (Your authorized KTM workshop will be glad to help.)
Warning
Danger of accidents Failure of brake system.
– If the foot brake lever is not released, the brake linings drag continuously. The rear brake may fail due to overheating. Take your
foot off the foot brake lever when you are not braking.

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
