KTM 690 SMC R User Manual

8 RIDING INSTRUCTIONS 53
Warning
Danger of accidents Longer stopping distance due to higher overall weight.
– Take the longer stopping distance into account when carrying a passenger and baggage.
Warning
Danger of accidents Delayed brake action on salted roads.
– There may be salt deposits on the brake discs. In order to restore the normal braking efficiency, you will need to remove the
deposits from the discs by carefully applying the brakes.
Warning
Danger of accidents Greater stopping distance due to ABS.
– Braking should be appropriate to the driving situation and the road conditions.
Warning
Danger of accidents Very forceful braking can cause the wheels to block.
– ABS must be switched on to be effective.
Warning
Danger of accidents Locking of the wheels due to braking action of the engine.
– Pull the clutch during emergency braking, full brake application and when braking on a slippery surface.
– When braking, release the throttle and apply the front and rear brakes at the same time.
Info
When the ABS is enabled, you can achieve maximum braking power even on low grip surfaces such as sandy, wet, or slippery
terrain without locking of the wheels.

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
