28 LIST OF SYMBOLS 191
28.1 Red symbols
Red symbols indicate an error condition that requires immediate intervention.
The temperature warning lamp lights up red The coolant temperature has reached a critical value.
The oil pressure warning lamp lights up red The oil pressure is too low.
The battery warning lamp lights up red The voltage in the vehicle system is too low.
28.2 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are also represented by yellow
or orange symbols.
The low fuel warning lamp lights up yellow The fuel level has reached the reserve mark. The display switches
to TRIP F.
FI warning lamp (MIL) lights up/flashes yellow The OBD has detected an emission- or safety-critical fault.
ABS warning lamp lights up/flashes yellow Status or error messages relating to ABS.
28.3 Green and blue symbols
Green and blue symbols reflect information.
The turn signal indicator lamp flashes green simultaneously with the turn signal The turn signal is switched on.

Table of Contents

Other manuals for KTM 690 SMC R

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 690 SMC R and is the answer not in the manual?

KTM 690 SMC R Specifications

General IconGeneral
Engine TypeSingle-cylinder, 4-stroke
Bore x Stroke105 mm x 80 mm
Compression Ratio12.7:1
StarterElectric starter
Transmission6-speed
Fuel SystemElectronic Fuel Injection
Cooling SystemLiquid cooled
FrameChromium-Molybdenum steel trellis frame, powder coated
Front Wheel3.50 x 17"
Rear Wheel5.00 x 17"
Front Tire120/70 ZR 17
Rear Tire160/60 ZR 17
Seat Height890 mm
Power55 kW (74 hp)
Torque73.5 Nm
Front SuspensionWP APEX 48
Rear SuspensionWP APEX with Pro-Lever linkage
Front BrakeSingle 320 mm disc, 4-piston caliper
Rear BrakeSingle 240 mm disc, 1-piston caliper
ABSBosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity13.5 liters
Dry Weight147 kg
