KTM 690 SMC R User Manual

9 SERVICE SCHEDULE 60
Every 20,000 km (12,428 mi) or every 2 years
Every 10,000 km (6,214 mi) or annually or after every sporting use
Once after 1,000 km (621.4 mi)
Grease all moving parts (e.g. side stand, hand lever, chain, ...) and check for smooth operation. ○ ● ●
Clean the dust boots of the fork legs. ( p. 72) ● ●
Check the front brake fluid level. ( p. 91) ○ ● ●
Check the steering head bearing play. ○ ● ●
Change fuel screen. ○ ● ●
Change the spark plug. ●
Check the valve clearance. ● ●
Check all hoses (e.g. fuel, cooling, bleeder, drainage, etc.) and sleeves for cracking, leaks, and incorrect routing. ●
Check the antifreeze and coolant level. ( p. 134) ○ ● ●
Check the cables for damage and routing without sharp bends. ● ●
Change the air filter. Clean the air filter box. ● ●
Check the fuel pressure. ● ●
Check the CO adjustment with the KTM diagnostics tool. ● ●
Check/rectify the fluid level of the hydraulic clutch. ( p. 87) ● ●
Check the screws and nuts for tightness. ○ ● ●
Change the rear brake fluid. ●
Change the rear brake fluid. ●
Check the headlight setting. ( p. 132) ○ ● ●
Check that the radiator fan is functioning properly. ○ ● ●
Final check: Check the vehicle for roadworthiness and take a test ride. ○ ● ●
Read out the fault memory using the KTM diagnostics tool after a test ride. ○ ● ●
Make the service entry in the KTM Dealer.net and in the Service and Warranty Booklet. ○ ● ●

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
