KTM 690 SMC R User Manual

19 STORAGE 158
– Recharge the battery. ( p. 117)
Guideline
Storage temperature of battery without
direct sunshine
0… 35 °C (32… 95 °F)
– Store the vehicle in a dry location that is not subject to large fluctuations in tempera-
ture.
Info
KTM recommends jacking up the motorcycle.
– Raise the motorcycle with the rear wheel stand. ( p. 70)
– Raise the motorcycle with the front wheel stand. ( p. 71)
– Cover the motorcycle with a tarp or cover that is permeable to air.
Info
Do not use non-porous materials since they prevent humidity from escaping,
thus causing corrosion.
Avoid running the engine for a short time only. Since the engine cannot warm
up properly, the water vapor produced during combustion condenses and causes
valves and exhaust system to rust.

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
