KTM 690 SMC R User Manual

21 BLINK CODE 167
Blink code FI of warning lamp
(MIL)
85 FI warning lamp (MIL) flashes 8x long, 5x short
Error level condition Accelerator position sensor circuit A - input signal too low
Accelerator position sensor circuit A - input signal too high
Blink code FI of warning lamp
(MIL)
86 FI warning lamp (MIL) flashes 8x long, 6x short
Error level condition Accelerator position sensor circuit B - input signal too high
Blink code FI of warning lamp
(MIL)
87 FI warning lamp (MIL) flashes 8x long, 7x short
Error level condition Accelerator position sensor circuit A and B - plausibility fault
Blink code FI of warning lamp
(MIL)
90 FI warning lamp (MIL) flashes 9x long
Error level condition Throttle position - circuit fault
DBW internal power relay - inactive
DBW internal power relay - active
Blink code FI of warning lamp
(MIL)
89 FI warning lamp (MIL) flashes 8x long, 9x short
Error level condition DBW return spring - stuck open

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
