KTM 690 SMC R User Manual

21 BLINK CODE 168
Blink code FI of warning lamp
(MIL)
92 FI warning lamp (MIL) flashes 9x long, 2x short
Error level condition DBW throttle actuator control IC - stuck open
Blink code FI of warning lamp
(MIL)
93 FI warning lamp (MIL) flashes 9x long, 3x short
Error level condition CPU mutual - surveillance error
Blink code FI of warning lamp
(MIL)
94 FI warning lamp (MIL) flashes 9x long, 4x short
Error level condition DBW stop function system error - stop function A system error
Blink code FI of warning lamp
(MIL)
95 FI warning lamp (MIL) flashes 9x long, 5x short
Error level condition DBW stop function system error - stop function B system error
Blink code FI of warning lamp
(MIL)
96 FI warning lamp (MIL) flashes 9x long, 6x short
Error level condition System voltage - input voltage too low
System voltage - input signal too high

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
