COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S87
9Y3200007CRS0125US0
Name Camshaft position sensor (G sensor) abnormality
ISO 14229
P-Code
P0340 P0341
J1939-73
SPN 723 723
FMI 82
SPN Name
SAE J1939 Table C1
Engine Speed 2 Engine Speed 2
DTC Name
No input of G sensor (Camshaft position
sensor) pulse
G sensor (Camshaft position sensor) pulse
number error
Detection item
Open circuit or short circuit of sensor /
harness
Failure of sensor
Open circuit or short circuit of sensor /
harness
Failure of sensor
DTC Set
Preconditions
Battery voltage is normal
Sensor supply voltage VCC# is normal
Engine is not stalled
Battery voltage is normal
Sensor supply voltage VCC# is normal
Engine speed is 350 min
-1
(rpm) or
higher
DTC set parameter
No recognition of G sensor pulse Pulse count per rotation is not
5 teeth
Time to action or
number of error
detection
10 times or more 10 times or more
Limp Home Action
by engine ECU
(system action)
None None
Behaviour During
Malfunction
(Invalid G signal)
Engine hesitates at start-up
(Invalid G signal)
Engine hesitates at start-up
Engine Warning
Light
•ON •ON
Recovery from
error
Diagnostic counter = zero
or Key switch turn OFF
Diagnostic counter = zero
or Key switch turn OFF
Delay time for
recovery
Delay time varies with engine speed in
proportional relation
30 sec. at 800 min
-1
(rpm), 15 sec. at
1600 min
-1
(rpm)
Delay time varies with engine speed in
proportional relation
30 sec. at 800 min
-1
(rpm), 15 sec. at
1600 min
-1
(rpm)
Remark
KiSC issued 03, 2022 A
