COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S95
9Y3200007CRS0133US0
Name ECU FLASH ROM and CPU abnormality
ISO 14229
P-Code
P0605 P0606 P0606
J1939-73
SPN 628 1077 523527
FMI 222
SPN Name
SAE J1939 Table
C1
Program Memory Engine Fuel Injection Pump
Controller
Proprietary
DTC Name
ECU FLASH ROM error ECU CPU (Main IC) error ECU CPU (Monitoring IC)
error
Detection item
FLASH ROM error Failure of CPU Failure of monitoring IC
of CPU
DTC Set
Preconditions
Key switch is ON Key switch is ON
Battery voltage is 10 V or
more
Starter Switch signal
(Engine ECU: V12
terminal) is not activated
Key switch is ON
Battery voltage is 10 V or
more
Starter Switch signal
(Engine ECU: V12
terminal) is not activated
DTC set parameter
Check-sum error CPU fatal error Failure of monitoring IC
of CPU
Time to action or
number of error
detection
One time or more One time or more One time or more
Limp Home Action
by engine ECU
(system action)
Engine stopped without
delay
Engine Stop Engine Stop
Behaviour During
Malfunction
Engine stops Engine stops Engine stops
Engine Warning
Light
•ON •ON ON
Recovery from
error
Key switch turn OFF Key switch turn OFF Key switch turn OFF
Delay time for
recovery
–––
Remark
KiSC issued 03, 2022 A
