COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S108
9Y3200007CRS0144US0
Name Accelerator position sensor error (CAN)
Accelerator position sensor correlation
error
ISO 14229
P-Code
P2131 P2135
J1939-73
SPN 523543 91
FMI 22
SPN Name
SAE J1939 Table C1
proprietary Accel Pedal Sensor 1
DTC Name
Accelerator position sensor error (CAN) Accelerator position sensor correlation
error
Detection item
• Accelerator position sensor signal error
(sensor / harness open circuit, ground
short circuit etc)
• Deviation from designed correlation in
two sensors
DTC Set
Preconditions
• Battery voltage is normal
• Key switch turn ON
• Starter Switch signal (Engine ECU: V12
terminal) is not activated
• Battery voltage is normal
• Accelerator position sensor 1 is normal
• Accelerator position sensor 2 is normal
DTC set parameter
• Accelerator position sensor error signal
received by CAN
• Deviation from designed correlation in
two sensors
Time to action or
number of error
detection
• Transient • Transient
Limp Home Action
by engine ECU
(system action)
• Not applicable • Forced Idle
(Accelerator = 0 %)
Behaviour During
Malfunction
• Insufficient output • Insufficient output
Engine Warning
Light
•ON •ON
Recovery from
error
• Diagnostic counter = zero
or Key switch turn OFF
(CAN signal recovers)
• Diagnostic counter = zero
or Key switch turn OFF
Delay time for
recovery
• Immediately • 3 sec.
Remark
