COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S114
9Y3200007CRS0150US0
Name EGR (DC motor) abnormality
ISO 14229
P-Code
P2413 P2414 P2415
J1939-73
SPN 523575 523576 523577
FMI 722
SPN Name
SAE J1939 Table
C1
proprietary proprietary proprietary
DTC Name
EGR actuator valve stuck EGR (DC motor) overheat EGR (DC motor)
temperature sensor failure
Detection item
EGR actuator valve stuck EGR (DC motor)
overheat
EGR (DC motor)
temperature sensor
failure
DTC Set
Preconditions
Battery voltage is normal
No DTC of U0077 "CAN1
Bus off"
EGR control line is
normal
Battery voltage is normal
No DTC of U0077 "CAN1
Bus off"
EGR control line is
normal
Battery voltage is normal
No DTC of U0077 "CAN1
Bus off"
EGR control line is
normal
DTC set parameter
EGR actuator valve stuck
error signal received via
CAN
EGR (DC motor)
temperature error signal
(thermistor: 125 °C
(257 °F) or more)
received via CAN
EGR (DC motor)
temperature sensor error
signal received via CAN
Time to action or
number of error
detection
2.8 sec. or more 2.8 sec. or more 2.8 sec. or more
Limp Home Action
by engine ECU
(system action)
Output limitation:
Approximately 75 % of
normal condition
•EGR stop
Output limitation:
Approximately 75 % of
normal condition
•EGR stop
Output limitation:
Approximately 75 % of
normal condition
•EGR stop
Behaviour During
Malfunction
Insufficient output
Worsening exhaust gas
performance
Insufficient output
Worsening exhaust gas
performance
Insufficient output
Worsening exhaust gas
performance
Engine Warning
Light
•ON •ON •ON
Recovery from
error
Key switch turn OFF Key switch turn OFF Key switch turn OFF
Delay time for
recovery
–––
Remark
KiSC issued 03, 2022 A
