COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S115
9Y3200007CRS0151US0
Name Exhaust gas temperature sensor (T
2
) abnormality
ISO 14229
P-Code
P242C P242D
J1939-73
SPN 3246 3246
FMI 43
SPN Name
SAE J1939 Table C1
Aftertreatment 1 Diesel Particulate Filter
Outlet Gas Temperature
Aftertreatment 1 Diesel Particulate Filter
Outlet Gas Temperature
DTC Name Exhaust gas temperature sensor 2: Low Exhaust gas temperature sensor 2: High
Detection item
Ground short circuit of sensor / harness Open circuit or +B short circuit of sensor
/ harness
DTC Set
Preconditions
Battery voltage is normal Battery voltage is normal
Coolant temperature is 50 °C (122 °F) or
more: continues longer than 10 min. after
engine starting
100 °C (212 °F) T
0
800 °C (1472 °F):
continues longer than 10 sec. or 100 °C
(212 °F) T
1
800 °C (1472 °F):
continues longer than 10 sec.
DTC set parameter
Exhaust gas temperature sensor (T
2
)
voltage: 0.08 V or less
Exhaust gas temperature sensor (T
2
)
voltage: 4.92 V or more
Time to action or
number of error
detection
5 sec. or more 120 sec. or more
Limp Home Action
by engine ECU
(system action)
0 °C (32 °F) [default value]
Output limitation: Approximately 75 % of
normal condition
0 °C (32 °F) [default value]
Output limitation: Approximately 75 % of
normal condition
Behaviour During
Malfunction
None None
Engine Warning
Light
•ON •ON
Recovery from
error
Key switch turn OFF Key switch turn OFF
Delay time for
recovery
––
Remark
KiSC issued 03, 2022 A
