COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S118
9Y3200007CRS0154US0
Name Emission deterioration
ISO 14229
P-Code
P3001
J1939-73
SPN 3252
FMI 0
SPN Name
SAE J1939 Table C1
Aftertreatment 1 Exhaust Gas
Temperature 2 Preliminary FMI
DTC Name Emission deterioration
Detection item • DOC is heated up due to unburned fuel
DTC Set
Preconditions
• Other than during regeneration mode
• Coolant temperature is 50 °C (122 °F) or more: continues longer than 5 min. after
engine starting
DTC set parameter •T
1
− T
0
≥ 250 °C (482 °F)
Time to action or
number of error
detection
• 60 sec. or more
Limp Home Action
by engine ECU
(system action)
• Output limitation: Approximately 50 % of normal condition
• Speed limitation (Accelerator limitation: 50 %)
•EGR stop
• Intake throttle 100 % open
Behaviour During
Malfunction
• Insufficient output
Engine Warning
Light
•ON
Recovery from
error
• Key switch turn OFF
Delay time for
recovery
–
Remark • To minimize PM emission to DPF
