COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S126
9Y3200007CRS0161US0
Name
All exhaust gas temperature sensor
failure
Initial pump-calibration incomplete
ISO 14229
P-Code
P3018 P3019
J1939-73
SPN 523599 523600
FMI 00
SPN Name
SAE J1939 Table C1
proprietary proprietary
DTC Name All exhaust gas temperature sensor failure Initial pump-calibration incomplete
Detection item
• All exhaust gas temperature sensor
failure simultaneously
• Pump-calibration history
DTC Set
Preconditions
• Engine speed is 1400 min
-1
(rpm) or
more
• Quantity of injection is 5 mm
3
/st or more
• Coolant temperature is 50 °C (122 °F) or
more: continues longer than 300 sec.
• Passed 100 sec. after cranking
• Battery voltage is normal
DTC set parameter
• All exhaust gas temperature sensor
failure (sensor low) simultaneously
• Initial pump calibration incomplete
Time to action or
number of error
detection
• 100 sec. or more • Transient
Limp Home Action
by engine ECU
(system action)
• Output limitation: Approximately 75 % of
normal condition
•None
Behaviour During
Malfunction
•None •None
Engine Warning
Light
•ON •ON
Recovery from
error
• Diagnostic counter = zero
or Key switch turn OFF
• Diagnostic counter = zero
or Key switch turn OFF
Delay time for
recovery
• Immediately • Immediately
Remark
To Next Page
