COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S130
9Y3200007CRS0165US0
Name CAN2 frame error
ISO 14229
P-Code
U0081 U0082 U0083
J1939-73
SPN 523548 523591 523592
FMI 222
SPN Name
SAE J1939 Table
C1
proprietary proprietary proprietary
DTC Name
CAN-KBT frame error CAN CCVS (Parking SW
and Vehicle Speed) frame
error
CAN CM1 (Regen SW)
frame error
Detection item
• CAN-KBT original frame
open circuit error
• CAN_CCVS
communication stopping
•CAN_CM1
communication stopping
DTC Set
Preconditions
• Battery voltage is normal
• Key switch turn OFF to
ON
• Starter Switch signal
(Engine ECU: V12
terminal) is not activated
• No error of "CAN2 Bus
off"
• Battery voltage is normal
• Starter Switch signal
(Engine ECU: V12
terminal) is not activated
• Battery voltage is normal
• Starter Switch signal
(Engine ECU: V12
terminal) is not activated
DTC set parameter
• CAN2 KBT frame open
circuit error
• CAN CCVS frame time
out error
• CAN CM1 frame time out
error
Time to action or
number of error
detection
• Transient • 0.5 sec. or more • 2.0 sec. or more
Limp Home Action
by engine ECU
(system action)
• Forced Idle
(Accelerator = 0 %)
• Parking SW = OFF,
Vehicle speed = 0
[default value]
• Regeneration inhibit =
ON, Parked regeneration
SW = OFF [default value]
Behaviour During
Malfunction
• Insufficient output • None • None
Engine Warning
Light
•ON •ON •ON
Recovery from
error
• Key switch turn OFF • Key switch turn OFF • Key switch turn OFF
Delay time for
recovery
–––
Remark
