COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S163
2. DTC Judgment
1. Place the key switch in the OFF position, attach the diagnosis
tool to the CAN1 connector, and return the key switch to the ON
position again.
2. Operate the engine for 2 to 3 minutes with the engine in the idle
status.
3. Clear the DTC, and check whether the same DTC (P0102) is
output again or not.
4. Check the "HMI for NCD" screen and confirm that no warning is
displayed.
5. Check whether the device is under tampering.
9Y3200007CRS0562US0
Service
specification
No DTC is output and no warnings are displayed.
OK Normal.
NG Replace the MAF Sensor or engine ECU then "DTC Judgment" again.
(a) CAN1 Connector
To Next Page
