COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-M26
NOTE
• Each engine ECU is pin compatible. The pin
assignment is the same.
9Y3200007CRM0019US0
(1) Engine ECU Wiring Harness
Connector 1 (Engine Side)
(2) Engine ECU Connector 1
(Engine Side)
(3) Engine ECU Connector 2
(Machine Side)
(4) Engine ECU Wiring Harness
Connector 2 (Machine Side)
(5) E01 Pin Position
(6) V01 Pin Position
(A) Engine ECU (Denso)
(B) Engine ECU (Kubota)
