COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S334
11. Check the Key Switch - 2
1. Measure the voltage at the key switch input terminal (1).
9Y3200007CRS0544US0
Service
specification
10 V or higher
OK Check the key switch. → Replace.
NG Check the wiring harness between the battery and key switch, and the
fuse. → Replace.
(1) Input Terminal
(2) ACC
(3) Output Terminal
(4) START
(a) Key Switch
