Kuka KUKA.PLC mxAutomation Logix 1.0 User Manual

107 / 123Issued: 13.08.2012 Version: KST PLC mxAutomation Logix 1.0 V1 en (PDF)
8 Messages
454 INVALID TOOL
NUMBER FOR
LOAD_DATA
An invalid number has been
programmed in the function
block KRC_ReadLoadData or
KRC_WriteLoadData for read-
ing or writing the load data or
supplementary load data.
Program a valid value (parame-
ter Tool).
(>>> 7.6.23 "Reading the load
data" Page 51)
(>>> 7.6.24 "Writing load data"
Page 52)
455 INVALID ANALOG
IO NUMBER
An invalid value has been pro-
grammed in a function block for
the velocity.
Program a valid value (parame-
ter Number):
 1 … 32
456 INVALID
IPO_MODE
An invalid value has been pro-
grammed in a function block for
the interpolation mode, e.g. in a
KRC_Move function block.
Program a valid value (parame-
ter CoordinateSystem –
COORDSYS.IPO_MODE).
457 INVALID
CIRC_TYPE
An invalid value has been pro-
grammed in a KRC_MoveCirc
function block for the orienta-
tion control during the circular
motion.
Program a valid value (parame-
ter CircType).
(>>> "CircType" Page 28)
458 INVALID FRAME
DATA
Invalid TOOL or BASE data
have been programmed in a
KRC_WriteToolData or
KRC_WriteBaseData function
block.
Program valid data (parameter
ToolData or BaseData).
(>>> 7.6.20 "Writing TOOL
data" Page 48)
(>>> 7.6.22 "Writing BASE
data" Page 50)
459 INVALID LOAD
DATA
Invalid load data have been
programmed in a
KRC_WriteLoadData function
block.
Program valid data.
(>>> 7.6.24 "Writing load data"
Page 52)
460 INVALID
SOFT_END
(REVERSED)
Error writing the software limit
switches: positive software limit
switch < negative software limit
switch
Program lower values for the
negative software limit switch
than for the positive software
limit switch.
461 INVALID INTER-
RUPT STATE
Internal exceptional error Contact KUKA Roboter GmbH.
(>>> 9 "KUKA Service"
Page 111)
462 INVALID SYS VAR
INDEX
An index for which no system
variable is stored has been
transferred in a
KRC_ReadSysVar or
KRC_WriteSysVar function
block.
Program a valid value (parame-
ter Index).
(>>> 7.9.1 "Reading system
variables" Page 90)
(>>> 7.9.2 "Writing system
variables" Page 91)
463 INVALID SYS VAR
VALUE
An invalid value has been pro-
grammed in a
KRC_WriteSysVar function
block for the system variable.
Program a valid value (parame-
ter Value1 … Value10).
(>>> 7.9.2 "Writing system
variables" Page 91)
464 SYS VAR NOT
WRITEABLE
An error occurred when writing a system variable.
The specified system variable does not exist or may not be written
in the current operating state.
465 INVALID REAL
VALUE
The programmed Real value is
invalid.
Program a valid value:
 -2,147,483,500 …
+2,147,483,500
No. Message text Cause Remedy
