Kurz B Series User Manual

KurzB‐SeriesOperationsGuide 1–19
B‐SeriesFlowMeterModes & Menus
Quick Reference Card
YoushouldhavereceivedaQuickReferenceCardsimilartotheoneshowninFigure 1‐4.Inthe
eventthecardismissingoryouneedextracards,printthefollowingQuickReferenceCard.

Figure 1‐4. Userinterfacequickreferencecard
Home Key
Back out of menu system
Clears input in Program mode
Acknowledge meter event
Program mode
Page display
Display mode
Delete (backspace) in Program mode
Enter key (accept user input)
Function
Key Sequence
Basic setup
Advanced setup
(Menu Scroll)
Advanced setup
(Quick Jump)
H
C
P
D
E
P‐123456‐E
P‐654321‐E‐1
P‐654321‐E‐2
Tag Name
Flow Units
Flow Area
Probe Depth (insertion meter)
4‐20 mA AO #1 Setup
4‐20 mA AO #2 Setup
Setup Run Mode Display
Basic Setup Menu Items
Kurz Instruments, Inc.
B–Series v2.0
Quick Reference Card
Function Option #
Program Mode (Quick Jump)
Basic Meter Setup 1
Flow Cutoff Setup 2
Flow CF and TC 3
Flow Totalizer Setup 4
4-20 mA AO #1 Setup 5
4-20 mA AO #2 Setup (optional)6
Run Mode Display Setup 7
Relay Outputs Setup 8
Alarms Setup 9
Pulse Output Setup 11
Calibrate Analog Outputs 14
Gas Setup 17
Drift Check Setup 23
Display Mode (Quick Jump)
Sensor Serial Number 32
Model Number 34
Flow Meter Data 42
Input Voltage 44
Sensor Output 45
Event Code 49
Firmware Version 50
