Kurz B Series User Manual

KurzB‐SeriesOperationsGuide 2–11
B‐SeriesFlowMeterDisplay Mode Options
Option 8 — Relays
TheB‐Serieshastwosolidstaterelaysratedfor+/‐30VDCor24VACupto0.5ARMSload.
Each relaycanonlybeassignedonefunctionatatime.
ToviewtheRelayOutputsSetupmenuinDisplaymode:
1> PressD.
2> Press 2toinvoketheQuickJumpoption.
3> Press8fortheRelayOutputsSetupmenu,andthenpressE.
SELECT RELAY #
>1
TheSelectRelay Numberpromptappears.
4> PressPtocontinue.
Relay#1isassignedtotheALARMOUTPUTandTOTPULSEOUTfunctions.
Relay #2isassignedtotheALARMOUTPUT,TOTPULSEOUT,PURGEOUTPUT
functions.
ASSIGN RELAY TO
>ALARM OUTPUT
5> PressPtoreviewthesettingsforthesecondrelaynumber,orpressHtoexit.
ThemainDisplaymode(DSP)promptappears.
^
^
