Kurz B Series User Manual

KurzB‐SeriesOperationsGuide2–24
B‐SeriesFlowMeterDisplay Mode Options
Viewing the External Analog Input for Multiple Gas Curves
ToviewtheExternalAnalogInputinDisplaymode:
1> PressD.
2> Press 2toinvoketheQuickJumpoption.
3> Press41fortheinputcurrentandtheequivalentgascurve.
INPUT CURRENT
AT 0.012 mA
Theinputcurrentreadbytheflowmeterappears.UseTable 6‐3todeterminethe
activecalibrationcurvebeingusedbytheflowmeter.
4> PressHtoexit.
ThemainDisplaymode(DSP)promptappears.
