KurzB‐SeriesOperationsGuide4–14
Program ModeAdvanced Setup
Option 6 — Setting Up Analog Output 2
Theoutputandsignalrangeforprocessvariablesmeasuredbytheflowmeterareconfigured
throughtheAnalogOutputSetupmenuinProgramMode.Thereceivingdevicemustbe
programmedforthesamerange.
Theflowmetersupportsuptotwoanalogoutput(AO)channels.Eachanalog outputchannel
(AO1and
AO2)canreportflowrate,temperature,velocity,orbeassignedtoaPIDflowcontroller.
Bothchannelsareactiveduringthezero‐mid‐spandriftcheck.

ThedriftcheckandNE‐43alarmsaretemporaryoverridestotheanalogoutputsignals.

ToaccesstheAnalogOutputSetupmenuinProgr ammode:
1> PressP.
2> EntertheAdvancedaccesscodeandthenpressE.
3> Press 2toinvoketheQuickJumpoption.
4> Press6fortheAnalogOut2menu,andthenpressE.
ThefollowingexampleusestheAnalogOut2optionwiththeflowratefeature.
ANALOG OUT 2 >
FLOW RATE ^v
5> Usethearrow keystoscrollthroughthelist,thenpressE.
AO2 at 4mA
>0.00000000 SCFM
Table 4‐3. 4‐20mAOutputFunctions
AnalogOutputFunctions Description
Flowrate
Processmeasurement.Temperature
Velocity
PIDflowcontroller Controlvalveposition,damperposition,or
motorcontrollerspeed.
Table 4‐4. Temporary4‐20mAProcessMeasurementOverride
DriftCheck NE‐43Alarms
Trigger Internaltimer
Flowmetererrorconditions.
Trigger DI2input
