KurzB‐SeriesOperationsGuide 2–19
B‐SeriesFlowMeterDisplay Mode Options
Option 27 — WGF Vapor Correction Factor
ToviewtheVaporCorrectionFactorinformationinDisplaymode:
1> PressD.
2> Press 2toinvoketheQuickJumpoption.
3> Press27fortheWGFParametersmenu,andthenpressE.
WGF CORRECTION
>ENABLED
Thisdeterminesifthecorrectionforcondensinggasisturnedonoroff.
4> PressPtocontinue.
PROCESS TMAX
>100.00000000 DEGF
TheProcessTMAXistheestimatedmaximumsaturationtemperatureinthepipe.
Foradigesterapplication,thiswillmatchthedigestertemperature(atypicaldigester
operatesat100°F).Ifthisvalueissettoohigh,itwill overcorrectthewet ‐to‐dryflow
rate.TheunitofmeasurementiseitherCelsius
orFahrenheit.IftheTMAXvalueisset
tozero(0.0),theflowmeterwilloutputthecondensinggasflowrate,effectively
disablingthecorrection.
5> PressPtocontinue.
PROCESS PRESSURE
>14.7000000 PSI
TheProcessPressureisthepressureinthelinewheretheflowisbeingmeasured.The
unitofmeasurementiseitherkPAorPSI.
6> PressHtoexit.
ThemainDisplaymode(DSP)promptappears.
^
^
