KurzB‐SeriesOperationsGuide2–30
B‐SeriesFlowMeterDisplay Mode Options
Option 47 — Electronics Temperature
ToviewtheElectronicsTemperaturemenuinDisplaymode:
1> PressD.
2> Press 2toinvoketheQuickJumpoption.
3> Press47fortheElectronicsTemperaturemenu,andthenpressE.
ELECTRONICS TEMP
98.484 DEGF
Thepromptindicatingthetemperatureinsidetheelectronicsenclosureappears.
4> PressHtoexit.
ThemainDisplaymode(DSP)promptappears.
Option 48 — Sensor Leakage
Note ThisOptionisusedbyKurzfordiagnosticandtroubleshootingpurposes.
ToviewtheSensorLeakagemenuinDisplaymode:
1> PressD.
2> Press 2toinvoketheQuickJumpoption.
3> Press48fortheSensorLeakagemenu,andthenpressE.
SENSOR LEAKAGE
21014 K
TheSensorLeakagepromptappears.Anormalmeasurementisgreaterthan100kΩ.
4> PressHtoexit.
ThemainDisplaymode(DSP)promptappears.
