KurzB‐SeriesOperationsGuide 3–7
Program ModeBasic Access
9> Usethenumberanddecimalkeystoentertheprobedepth.Press E.
ANALOG OUT
>FLOW RATE
^
v
TheAnalogOutputoptionsincludeflowrate,velocity,temperature,andPID.
Theavailabilityofoptionsisbasedonothersettings.
10> UsethearrowkeystoselectanAnalogOutputoption,andthenpress E.
AO1 at 4mA
>0.0000000 SCFM
Theanalogoutput4mApromptdeterminestheminimumrangevalue;thatis,thelow
processflowvalueequivalentto4mA.Theflowunitwasspecifiedinaprevious
option.
11> Usethenumberanddecimalkeystoenterthe4mAvalue.Press E.
AO1 at 20mA
>15000.000 SCFM
Theanalogoutput20 mApromptdeterminesthemaximumrangevalue;thatis,the
highprocessflowvalueequivalentto20 mA.Theflowunitwasspecifiedinaprevious
option.
12> Usethenumberanddecimalkeystoenterthe20 mAvalue.Press E.
Note:Iftheflowmeterwasconfiguredwithasecondanalogoutput,prompts
willappearforAO2at4mAandAO2at20 mA.
RUN MODE DISPLAY
>STATIC
^
v
TheRunModeoptionsarestaticvariablesandscrolledvariables.
Referto“RunMode”onpage 1‐6 foradescriptionofstaticandscrolledmodes.
13> Usethearrow keystoselecttheRunModeDisplay,andthenpressE.
Dependingontherunmodeselection,thestaticvariableorscrolledvariablesprompt
appears.
STATIC VARS
>FLOW+TEMP
^
v
SCROLLED VARS
>SCROLL ALL
^
v
