KurzB‐SeriesOperationsGuide4–20
Program ModeAdvanced Setup
Themeterwillreassigntherelaytothenewfunction.Thepreviouslyassignedfunction
isnowunassignedandturnedoff,whenapplicable.
— AnexampleofwhenthefunctionisturnedoffisifRelay#2isassignedtothe
PURGEOUTfunctionandthenreassignedtotheTOTALIZERPULSEOUTPUTandthe
PURGETIMERisON.ThemeterwillturnOFFthePURGETIMERwhentherelayis
reassigned.
— Anex ampleofwhenthefunctionisnotturnedoffiswhenarelayisassignedtothe
ALARMOUTPUTfunctionandthenreassignedtoanotherfunction,thealarmisnot
turnedOFF.Onlytheactuationoftherelayduetothetriggeredalarmisdisabled,
andthealarmwillremain
ONandcontinuetotriggerasconfigured.
Iftheflowmeterisconfiguredwithmorethan1relayoutput,themeterwillrepeatthe
sequenceofpromptstoconfiguretheotherrelayoutput.
8> PressHtoexittheSetupRelayOutputsmenu.
Onceafunctionisconfiguredfortheselectedrelaynumber,themeterwi ll advanceto
thesetupmenuforthatfunction.
Dependingonthefunctionthatisbeingassociatedwiththerelay,themenuautomaticallyjumps
toOption9(Alarmsetup),Option10
(NE‐43alarmsetup),Option11(pulseoutput),orOption12
(sensorpurgeoutput).
