Kyocera KM-3050

2GN/2GP/2GR-5
1-3-74
U411 5. Select the item (place all oroginals face down).
[INPUT]
1. Select [INPUT].
2. Place a specified original (P/N: 2AC68241).
3. Press the start key. Auto adjustment starts.
4. To return to the screen for selecting an item, press the stop key.
[GAMMA]
1. Select [GAMMA].
2. Place a specified original (P/N: 303JX57010).
3. Press the start key. Auto adjustment starts.
4. To return to the screen for selecting an item, press the stop key.
[MTF/MATRIX]
1. Select [MTF/MATRIX].
2. Place a specified original (P/N: 303JX57020).
3. Press the start key. Auto adjustment starts.
4. To return to the screen for selecting an item, press the stop key.
When [ALL] is selected, the adjustment of [INPUT], [GAMMA] and [MTF/MATRIX] can be executed at once.
When adjusting, place the three specified originals, and then press the start key.
Set the original 303JX57020, and then place 303JX57010 and 2AC68241 in order on the top of the original.
When automatic adjustment has normally completed, [RESULT OK 00] is displayed. If a problem
occurs during auto adjustment, [ERROR XX] (XX is replaced by an error code) is displayed and opera-
tion stops. Should this happen, determine the details of the problem and either repeat the procedure
from the beginning, or adjust the remaining items manually by running the corresponding maintenance
items.
Completion
Press the stop key. The screen for selecting a maintenance item is displayed.
Maintenance
item No.
Description
Display Description Original to be used for
adjustment (P/N)
ALL Automatic adjustment of second page using the DP
for: original size magnification/leading edge timing/
center line, input gamma, chromatic aberration filter,
MTF filter and matrix.
2AC68241/303JX57010/
303JX57020
INPUT Automatic adjustment of second page using the DP
for: original size magnification/leading edge timing/
center line.
2AC68241
GAMMA Automatic adjustment of second page using the DP
for: input gamma.
303JX57010
MTF/MATRIX Automatic adjustment of second page using the DP
for: MTF filter and matrix.
303JX57020
