Kyocera KM-3050

2GN/2GP/2GR-1
1-5-38
(2) Detaching and refitting the dust filter 1 and 2
Follow the procedure below to replace the dust filter 1 and 2.
Procedure
1. Open the MP tray.
2. Remove the dust filter 1 and 2 from the
machine.
3. Replace the dust filter 1 and 2 and install the
filters.
Figure 1-5-77
Dust filter 1
Dust filter 2
