Kyocera KM-3050

2GN/2GP/2GR-7
1-3-86
U935
Relay board maintenance
Description
Sets the machine status temporarily when call for service (C0060) occurs. However, after the setting, call for
service (C0060) occurs again when progress of period.
Setting
1. Press the start key.
2. Select the item.
Initial setting: MODE 0
3. Press the start key. The setting is set.
4. Turn the main power switch off and on.
Supplement
After removing the cause of the problem, be sure to change the setting in OFF.
U942
Setting of deflection for feeding from DP
Description
Adjusts the deflection generated when the optional DP is used.
Purpose
Use this mode if an original non-feed jam, oblique feed or wrinkling of original occurs when the DP is used.
Setting
1. Press the start key.
2. Select the item to be adjusted.
3. Press the system menu key.
4. Place an original on the DP and press the start key to make a test copy.
5. Press the system menu key.
6. Change the setting value using the +/- or numeric keys.
The greater the value, the larger the deflection; the smaller the value, the smaller the deflection.
If an original non-feed jam or oblique feed occurs, increase the setting value. If wrinkling of original
occurs, decrease the value.
7. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
MODE 0 Setting mode: OFF
MODE 1 Setting mode: ON (Usable up to three times of use)
Display Description Setting
range
Initial
setting
Change in
value per step
REGIST Deflection in the reading original from
the DP
-31 to 31 0 0.17 mm
REGIST MIX Deflection in the reading original from
the DP in the auto selection mode
-31 to 31 0 0.17 mm
