Kyocera KM-3050

2GN/2GP/2GR-7
1-3-48
U203
Checking DP operation
Description
Simulates the original conveying operation separately in the optional DP.
Purpose
To check the DP operation.
Method
1. Press the start key.
2. Place an original in the DP if running this simulation with paper.
3. Select the item to be operated.
4. When selecting [TEST2], to set the magnification using the +/- keys.
5. Press the start key. The operation starts.
6. To stop continuous operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U204
Setting the presence or absence of a key card or key counter
Description
Sets the presence or absence of the optional key card or key counter.
Purpose
To run this maintenance item if a key card or key counter is installed.
Method
1. Press the start key.
2. Select the item to be set. The setting screen for the selected item is displayed.
Setting: KEY-DEVICE
1. Select ON or OFF.
2. Press the start key. The setting is set.
3. Turn the main power switch off and on.
Setting: MESSAGE
1. Select the [COUNTER], [CARD] or [COIN].
2. Press the start key. The setting is set.
3. Turn the main power switch off and on.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U206
Setting the presence or absence of the coin vender
Description
Sets the presence or absence of the optional coin vender. Also sets the details for coin vender operation, such
as mode and unit price.
This is an optional device which is currently supported only by Japanese specification machines, so no setting
is necessary.
Maintenance
item No.
Description
Display Operation Setting range Initial setting
TEST 1(NON P) Without paper - -
TEST 2 With paper 100 to 200 (%) 100
Display Description
KEY-DEVICE Sets the presence or absence of the key card or key counter
MESSAGE Sets the message when optional equipment is not installed
Display Description
ON The key card or the key counter is installed
OFF Not installed
