Kyocera KM-3050

2GN/2GP/2GR-2
1-3-55
U241
Method: Checking the switch of the mailbox
1. Turn the respective switches on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
Method: Checking the switch of the centerfold unit
1. Turn the respective switches on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U243
Checking the operation of the DP motors
Description
Turns the motors in the optional DP on.
Purpose
To check the operation of the DP motors.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key when operation stops. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Switches
FEED IN SW Mail paper entry switch (MPESW)
EJECT SW Tray eject sensor (TEJS)
COVER SW Mailbox cover open/close switch (MBCOSW)
OVER FLOW SW 1 Tray overflow switch 1 (TOFSW1)
OVER FLOW SW 2 Tray overflow switch 2 (TOFSW2)
OVER FLOW SW 3 Tray overflow switch 3 (TOFSW3)
OVER FLOW SW 4 Tray overflow switch 4 (TOFSW4)
OVER FLOW SW 5 Tray overflow switch 5 (TOFSW5)
OVER FLOW SW 6 Tray overflow switch 6 (TOFSW6)
OVER FLOW SW 7 Tray overflow switch 7 (TOFSW7)
Display Switches
BUNDLE UP HP SW Centerfold paper conveying belt sensor 1 (CPCBS1)
BNDL DOWN HP SW Centerfold paper conveying belt sensor 2 (CPCBS2)
BLADE HP SW Blade home position sensor (BLHPS)
WIDTH HP SW U Centerfold side registration sensor 2 (CSRS2)
WIDTH HP SW L Centerfold side registration sensor 1 (CSRS1)
FEED IN SW Centerfold paper entry sensor (CPES)
PAPER DET SW Centerfold paper detection sensor (CPDS)
TRAY PAP DET SW Tray paper detection sensor (TPDS)
EJECT SW Centerfold eject switch (CESW)
TRAY DET SW Centerfold top cover switch (CTCSW)
Display Motors
DP FEED MOTOR Original feed motor (OFM) is turned on.
DP REG MOTOR Original registration motor (ORM) is turned on.
DP CONV MOTOR Original conveying motor (OCM) is turned on.
DP LIFT MOTOR DP lift motor (DPLM) is turned on.
CIS FAN MOTOR DP fan motor 1,2,3 (DPFM1,2,3) is turned on.
DP FEED MOT REV Original feed motor (OFM) is turned on reversing.
