2GN/2GP/2GR-7
2-4-2
Maintenance kits
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Eject roller ROLLER EXIT 302BL21021 2BL21021 8 26
Switchback roller ROLLER FEED SHIFT 302BL21031 2BL21031 8 27
Eject pulley PULLEY EXIT C 2BL21520 - 8 24
Eject pulley PULLEY EXIT 302GR28060 2GR28060 8 34
Switchback pulley PULLEY FEED SHIFT 2BL21330 - 6 33
Dust filter 1 PARTS FILTER DUST F1 ASSY 302GR94430 2GR94430 13 13
Dust filter 2 PARTS FILTER DUST F2 ASSY 302GR94440 2GR94440 13 14
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Maintenance kit <30ppm> MK-715 U (120 V specifications) 1702GN7US0 072GN7US 24 -
MK-715 E (220 - 240 V specifications) 1702GN8NL0 072GN8NL 24 -
MK-715 TW (110 V specifications) 1702GNTTW0 072GNTTW 24 -
Upper/lower paper feed pulley PULLEY,PAPER FEED - - - -
Upper/lower separation pulley PULLEY,SEPARATION - - - -
Upper/lower forwarding pulley PULLEY FEED A - - - -
Left registration cleaner UNDER CLEANER REGIST - - - -
Registration guide GUIDE REGIST F - - - -
Right registration cleaner PARTS,REGISTRATION CLEAN - - - -
Transfer guide PARTS,GUIDE TRANSFER - - - -
Drum unit DK-715 - - - -
Developing unit DV-715 - - - -
Fuser unit FK-715 U (120 V specifications) - - - -
FK-715 E (220 - 240 V specifications) - - - -
FK-715 TW (110 V specifications) - - - -
Transfer roller unit
TR-710
----
MP paper feed pulley
UPPER PULLEY,BYPASS
----
Maintenance kit <40/50 ppm> MK-716 U (120 V specifications) 1702GR7US0 072GR7US 24 -
MK-716 E (220 - 240 V specifications) 1702GR8NL0 072GR8NL 24 -
MK-716 TW (110 V specifications) 1702GRTTW0 072GRTTW 24 -
Upper/lower paper feed pulley PULLEY,PAPER FEED - - - -
Upper/lower separation pulley PULLEY,SEPARATION - - - -
Upper/lower forwarding pulley PULLEY FEED A - - - -
Left registration cleaner UNDER CLEANER REGIST - - - -
Registration guide GUIDE REGIST F - - - -
Right registration cleaner PARTS,REGISTRATION CLEAN - - - -
Transfer guide PARTS,GUIDE TRANSFER - - - -
Drum unit DK-716 - - - -
Developing unit DV-715 - - - -
Fuser unit FK-715 U (120 V specifications) - - - -
FK-715 E (220 - 240 V specifications) - - - -
FK-715 TW (110 V specifications) - - - -
Transfer roller unit
TR-710
----
MP paper feed pulley
UPPER PULLEY,BYPASS
----
