2GN/2GP/2GR
1-5-11
Removing the right registration cleaner
1. Remove the developing unit and drum unit.
(see pages 1-5-28 and 25).
2. Remove the right registration cleaner.
3. Replace the right registration cleaner and
Install the cleaner.
4. Refit the drum unit and developing unit.
Figure 1-5-25
Right registration cleaner
Frame
