Kyocera KM-3050

2GN/2GP/2GR-1
1-5-39
(3) Detaching and refitting the hard disk
Follow the procedure below to replace the hard disk.
Procedure
1. Remove the rear cover (see page1-5-12 ).
2. Remove fourteen screws and then remove
the inner cover.
3. Remove the one connector.
Figure 1-5-78
Screw(s)
Connector
Inner cove
r
Inner cover
Back side view
