Kyocera KM-3050

2GN/2GP/2GR-1
1-6-2
1-6-3 Remarks on main PWB replacement
When replacing the main PWB, remove EEPROM from the main PWB that has been removed and then reattach it to the
new main PWB.
Figure 1-6-2
1-6-4 Remarks on engine PWB replacement
When replacing the engine PWB, remove the EEPROM from the engine PWB that has been removed and then reattach it
to the new engine PWB.
Figure 1-6-3
EEPROM
Main PWB
EEPROM
(U3)
Engine PWB
