2GN/2GP/2GR
1-4-4
Paper
feed
section
18
Misfeed in vertical
paper conveying sec-
tion
The registration switch (RSW) does not turn on within
specified time of feed switch 1 (FSW1) turning on.
1657 ms (30 ppm)/
1283 ms (40/50 ppm)
Feed switch 1 (FSW1) does not turn on within specified
time of feed switch 2 (FSW2) turning on.
1910 ms (30 ppm)/
1478 ms (40/50 ppm)
Feed switch 2 (FSW2) does not turn on within specified
time of feed switch 3 (FSW3) turning on.
1904 ms (30 ppm)/
1474 ms (40/50 ppm)
19
Misfeed in paper feeder
vertical paper convey-
ing section
Feed switch 3 (FSW3) does not turn on within specified
time of the paper feeder feed switch (PFFSW) turning on.
1573 ms (30 ppm)/
1217 ms (40/50 ppm)
20
Misfeed in MP tray ver-
tical paper conveying
section
The registration switch (RSW) does not turn on within
specified time of the MP feed switch (MPFSW) turning
on.
3933 ms (30 ppm)/
3043 ms (40/50 ppm)
21
Multiple sheets in paper
feed section
The feed switch 1 (FSW1) does not turn off within speci-
fied time of its turning on.
Paper length +
4337 ms (30 ppm)/
Paper length +
3357 ms (40/50 ppm)
The feed switch 2 (FSW2) does not turn off within speci-
fied time of its turning on.
Paper length +
4337 ms (30 ppm)/
Paper length +
3357 ms (40/50 ppm)
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional paper
feeder).
3382 ms (30 ppm)/
2617 ms (40/50 ppm)
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional 3000-
sheet paper feeder).
Paper length +
1595 ms (30 ppm)/
Paper length +
1234 ms (40/50 ppm)
The paper feeder feed switch (PFFSW) does not turn off
within specified time of its turning on.
3382 ms (30 ppm)/
2617 ms (40/50 ppm)
The MP feed switch (MPFSW) does not turn off within
specified time of its turning on.
Paper length +
4337 ms (30 ppm)/
Paper length +
3357 ms (40/50 ppm)
The feed switch 1 (FSW1) does not turn off within speci-
fied time of the upper paper feed clutch (PFCL-U) turning
on.
1489 ms (30 ppm)/
1152 ms (40/50 ppm)
The feed switch 2 (FSW2) does not turn off within speci-
fied time of the lower paper feed clutch (PFCL-L) turning
on.
1562 ms (30 ppm)/
1209 ms (40/50 ppm)
The feed switch 3 (FSW3) does not turn off within speci-
fied time of the paper feeder paper feed clutch 1
(PFPFCL1) turning on.
3416 ms (30 ppm)/
2643 ms (40/50 ppm)
The paper feeder feed switch (PFFSW) does not turn off
within specified time of the paper feeder paper feed
clutch 2 (PFPFCL2) turning on.
5056 ms (30 ppm)/
3913 ms (40/50 ppm)
The MP feed switch (MPFSW) does not turn off within
specified time of the MP paper feed clutch (MPPFCL)
turning on.
5056 ms (30 ppm)/
3913 ms (40/50 ppm)
Section Description Conditions Specified time
