Kyocera KM-3050

2GN/2GP/2GR
2-3-3
YC6 1 24V O 24 V DC 24 V DC power output
Connected
to the scan-
ner PWB
2 24V O 24 V DC 24 V DC power output
3 24V O 24 V DC 24 V DC power output
4 PGND - - Ground
5 PGND - - Ground
6 PGND - - Ground
7 SGND - - Ground
8 SGND - - Ground
9 SGND - - Ground
10 SGND - - Ground
11 12V O 12 V DC 12 V DC power output
12 5V O 5 V DC 5 V DC power output
13 3.3V O 3.3 V DC 3.3 V DC power output
14 3.3V O 3.3 V DC 3.3 V DC power output
YC7
1 LIVE O 120 V AC
220-240 V AC
AC power output
Connected
to the
optional
cassette
heater
3 NEUTRAL O 120 V AC
220-240 V AC
AC power output
YC8 1 V24V O 24 V DC 24 V DC power output
Connected
to the
optional
paper
feeder,
optional
document
finisher and
hard disk
2 V24V O 24 V DC 24 V DC power output
3 5.1V O 5 V DC 5 V DC power output
4 PGND - - Ground
5 FGND - - Ground
6 PGND - - Ground
7 +12VD O 12 V DC 12 V DC power output
8 GND - - Ground
9 GND - - Ground
10 +5VD O 5 V DC 5 V DC power output
YC9 1 +24VD O 24 V DC 24 V DC power output
Connected
to the main
operation
PWB
2 +5VD O 5 V DC 5 V DC power output
3 +5VD O 5 V DC 5 V DC power output
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 N.C - - Not used
Connector Pin No. Signal I/O Voltage Description
