Kyocera KM-3050

2GN/2GP/2GR-2
2-3-12
YC16 1 +24VDR O 24 V DC 24 V DC power output
Connected
to the
optional
built-in fin-
isher
2 +24VDR O 24 V DC 24 V DC power output
3 GND - - Ground
4 GND - - Ground
5 +5VD O 5 V DC 5 V DC power output
6 GND - - Ground
7 SELECT O 0/5 V DC Built-in finisher SELECT signal
8 READY I 0/5 V DC Built-in finisher READY signal
9 SDI I 0/5 V DC (pulse) Built-in finisher serial communication data signal
10 SDO O 0/5 V DC (pulse) Built-in finisher serial communication data signal
11 SCLK O 0/5 V DC (pulse) Built-in finisher CLOCK signal
12 NC - - Not used
YC17 1 JBESW I 0/5 V DC JBESW: On/Off
Connected
to the
optional job
separator
2 +5VD O 5 V DC 5 V DC power output
3 GND - - Ground
4 GND - - Ground
5 SET SIG I 0/5 V DC Job separator connection signal
6 GND - - Ground
7 EPDSW I 0/5 V DC EPDSW: On/Off
8 +5VD O 5 V DC 5 V DC power output
9 LED REM O 0/5 V DC LED: On/Off
10 +5VD LED O 5 V DC 5 V DC power output
11 FSSOL2 O 0/24 V DC FSSOL: On/Off (return)
12 FSSOL1 O 0/24 V DC FSSOL: On/Off (activate)
13 +24VDR O 24 V DC 24 V DC power output
YC20 1 SCKN I 0/5 V DC (pulse) CLOCK signal
Connected
to the main
PWB
2 EGSI I 0/5 V DC (pulse) Serial communication data signal
3 EGSO O 0/5 V DC (pulse) Serial communication data signal
4 SBSY O 0/5 V DC SBSY signal
5 SDIR O 0/5 V DC SDIR signal
6 EGIRN O 0/5 V DC EGIRN signal
7 OUTPEN O 0/5 V DC OUTPEN signal
8 PVSYNC O 0/5 V DC (pulse) PVSYNC signal
9 +5VD O 5 V DC 5 V DC power output
10 SGND - - Ground
11 SGND - - Ground
12 LDON O 0/5 V DC LDON signal
13 PRST I 0/5 V DC PRST signal
14 PMD I 0/5 V DC PMD signal
15 HLDENG I 0/5 V DC HLDENG signal
YC22 1 GND - - Ground
Connected
to the cool-
ing fan
motor 14
2 CFM14 O 0/24 V DC CFM14: On/Off
Connector Pin No. Signal I/O Voltage Description
