2GN/2GP/2GR-1
1-2-9
1. Remove two screws from the rear cover.
2. Hook the catch of fixing brackets onto the
groove of round frame, and secure them
using two screws removed before step.
Figure 1-2-14
1. Attach the penholder and stylus pen to the
machine as necessary.
Figure 1-2-15
1. Turn the main power switch on and press the status key.
2. Enter the maintenance mode by entering 10871087 using the numeric keys.
3. Enter 130 using the numeric keys and press the start key.
4. Press the start key to execute the maintenance item. The drive stops within approximately 5 minutes.
5. Press the stop key.
Install the fixing brackets.
Fixing brackets
Grooves
Install the stylus pen and penholder.
Stylus pen
Penholder
Carry out initial developer setting (maintenance item U130).
To Next Page
