96 General Maintenance
Figure 3-96
Left-hand side proximity switch
7. Move the proximity switch laterally and perform tests until the chute stops at a position that will
prevent garbage from falling between the chute and the hopper wall.
In the cab, make sure that the corresponding indicator lights up.
8. Tighten up both screws.
9. Perform a test to make sure that there is no space between the chute and the hopper wall when
the chute is on the left-hand side (for more information on performing these tests, see Adjusting
Chute Proximity Switch Gaps (Co-Mingle Vehicles) on page 94).
Fuel Filter Replacement
Fuel filter needs to be replaced periodically according to manufacturer’s specifications. If your
A
UTOMIZER™ unit is a Mack LEU, special procedure must be followed to change the fuel filter.
To change the fuel filter of your A
UTOMIZER™ unit with a Mack LEU chassis, do the following:
1. Unclip the pipe from the collars.
2. Move the pipe close to the oil pan for more working space.
3. Proceed with the replacement of the fuel filter.
NOTE: Always follow your chassis manufacturer’s recommendations regarding fuel filter
replacement.
Proximity
switch
Bracket
Collars
Pipe
Fuel filter
