222 Lifting Arms
Figure 10-15
96-gal gripper holding valve
Figure 10-16
Cylinder-mounted holding valve (HD arm gripper)
Adjusting In/Out Holding Valve Pressure
NOTE: There is a holding valve mounted on the in/out cylinder (standard and HD).
To adjust the in/out holding valve pressure:
1. Apply all safety measures to ensure safety around the vehicle at all times.
2. Make sure that the parking brake is applied.
Gripper cartridge
(single finger side)
Gripper cartridge
(dual finger side)
Flow divider
Adjustable cartridge
