Troubleshooting 179
Figure 8-5
Plug to loosen
IMPORTANT: Do not activate any hydraulic function during system bleeding.
6. When the noise stops, tighten the pipe/hose fitting.
7. Cycle the packer to ensure that there are no leaks and the pump is running smoothly.
8. Disconnect the gauge.
Packer Air System
If the packer does not complete a full cycle, the problem may be related to the air system.
To fix the problem:
1. Apply all safety measures to ensure safety around the vehicle at all times.
2. Remove the optional cover (if applicable) over the valve to get access to the air tubes.
3. Remove the air tube from the actuator by pushing on the green sleeve with a screwdriver and
pulling the tube.
Figure 8-6
Removing the air tube from the actuator
Green
sleeve
Tube
