Safety 19
Putting the Tailgate Safety Prop Back in Place
To put the tailgate safety prop back in its home position:
1. Start the engine.
2. Turn on the pump.
3. Raise the tailgate by about 3 feet using the Tailgate Up switch on the in-cab control panel.
4. Raise the tailgate safety prop.
Figure 2-12
Raising the tailgate safety prop
5. Release your grip on the safety prop to set it in its home position.
Figure 2-13
Setting the safety prop in its home position
6. With the Tailgate Down switch on the in-cab control panel, completely close the tailgate.
The
TAILGATE OPEN light indicator should turn off.
